Mower deck boot connection
The boot kit connects the MC2014 Material Collection System to mid-mount mower decks on 1E, 1R, and 2R Series Tractors equipped with a mid-mount mower deck. Boot removal and installation is toolless for quick changing of implements (after initial installation). The boot is connected to the blower with a 203-mm (8-in.) diameter smooth bore hose to handle material throughput efficiently.
Blower hose connection from the deck boot to the impeller housing
Hose clamps use the helicoidal pattern on the hose to maintain a tight seal without adjustment during each installation. Clamps are retained and do not require tools to adjust (if required), providing a greater seal for increased suction. Easy access to the chute and boot for in-field removal of a clog is accomplished with tool-free clamps.
