Details New

Post Hole Diggers

PHD0 Series

Key Features & Specs
  • Dependable, rugged gearbox
  • Safety shielding covers auger and power take-off
  • Optional downforce kits
  • Optional hook-up stand

FEATURES
SPECIFICATIONS
EXPAND / CLOSE All
Dependable, rugged gearbox for long life
PHD0 Series Post Hole Digger gearbox PHD0 Series Post Hole Digger gearbox

The PHD0 Series Post Hole Digger has a rugged and dependable gearbox for a longer-lasting life.

Safety shielding covers auger and power take-off (PTO)
PHD0 Series Post-Hole Digger safety shield PHD0 Series Post-Hole Digger safety shield

The PHD0 Series Post-Hole Diggers have a strong safety shield surrounding the auger and PTO to provide extra protection and longer life.

Downforce kits for post hole diggers

The downforce kits are for post hole diggers as identified below.

NOTE: The downforce kit requires hydraulic pressure from a tractor selective control valve (SCV) and a pressure-free return.

Field-installed auger position handle kit for post-hole diggers

The auger position handle allows the operator to place the post-hole digger in the correct position before digging.



The field conversion auger position handle kit can be installed on PHD300 and PHD400 Series Post-Hole Diggers.

Field-installed hook-up stand kit for post-hole diggers
Great for mounting, dismounting, and storage Great for mounting, dismounting, and storage

The foldable hook-up stand allows operators to easily mount and dismount the post-hole digger from the tractor. The stand has several adjusting height options to accommodate the operator's needs.



The stand is ideal for storing the post-hole digger safely and prolongs the implement's life by keeping it off the ground.

Fishtail point standard on all augers
Post-hole auger point Post-hole auger point

The Frontier™ PHA0 Series Post-hole augers come with a fishtail point.

EXPAND / CLOSE All
Dimensions
Boom ODPHD100: 7.3 cm
2.875 in.
PHD200: 8.9 cm
3.5 in.
PHD300: Reinforced: 8.9 cm
PHD400: Reinforced: 8.9 cm
Yoke ODPHD100: 6 cm
2.375 in.
PHD200: 7.9 cm
2.875 in.
PHD300: Reinforced: 7.9 cm
PHD400: Reinforced: 7.9 cm
Auger speed
Gearbox
Tractor compatibility
Gearbox hp ratingPHD100: 18.6 kW
25 hp
PHD200: 29.8 kW
40 hp
PHD300: 37.3 kW
50 hp
PHD400: 67.1 kW
90 hp
PTO hp rangePHD100: 13.4-18.6 kW
18-25 hp
PHD200: 13.4-29 kW
18-40 hp
PHD300: 13.4-37.3 kW
18-50 hp
PHD400: 29.8-61.7 kW
40-90 hp
3-Point hitch
Weight
UnitPHD100: 50.8 kW
112 lb
PHD200: 90.7 kW
200 lb
PHD300: 104.3 kg
230 lb
PHD400: 117.9 kg
260 lb
Shipping (2 per case)PHD100: 149.7 kg
330 lb
PHD200: 213.2 kg
470 lb
PHD300: 249.5 kg
550 lb
PHD400: 276.7 kg
610 lb
Auger
Model numberPHD100: PHA006, PHA009, PHA012
PHD200: PHA106, PHA109, PHA112
PHD300: PHA106, PHA109, PHA112, PHA118, PHA124, PHA132
PHD400: PHA106, PHA109, PHA112, PHA118, PHA124, PHA132
Auger diameterPHA130: 76.2 cm (30 in.)
PHA006: 15.2 cm (6 in.)
PHA009: 22.9 cm (9 in.)
PHA012: 30.5 cm (12 in.)
PHA106: 15.2 cm (6 in.)
PHA109: 22.9 cm (9 in.)
PHA112: 30.5 cm (12 in.)
PHA118: 45.7 cm (18 in.)
PHA124: 61 cm (24 in.)
Auger lengthPHA130: 111.8 cm (44 in.)
PHA006: 91.4 cm (36 in.)
PHA009: 91.4 cm (36 in.)
PHA012: 91.4 cm (36 in.)
PHA106: 121.9 cm (48 in.)
PHA109: 121.9 cm (48 in.)
PHA112: 121.9 cm (48 in.)
PHA118: 121.9 cm (48 in.)
PHA124: 121.9 cm (48 in.)
Auger weightPHA130: 96.6 kg (213 lb)
PHA006: 10.9 kg (24 lb)
PHA009: 19.1 kg (42 lb)
PHA012: 23.6 kg (52 lb)
PHA106: 14.5 kg (32 lb)
PHA109: 24.9 kg (55 lb)
PHA112: 34 kg (75 lb)
PHA118: 36.3 kg (80 lb)
PHA124: 47.6 kg (105 lb)
Auger flighting typePHA130: Double
PHA006: Single
PHA009: Double
PHA012: Double
PHA106: Single
PHA109: Double
PHA112: Double
PHA118: Double
PHA124: Double
Auger thicknessPHA130: 7.9 mm (0.3125 in.)
PHA006: 4.8 mm (0.1875 in.)
PHA009: 4.8 mm (0.1875 in.)
PHA012: 4.8 mm (0.18725in.)
PHA106: 4.8 mm (0.1875 in.)
PHA109: 4.8 mm (0.1875)
PHA112: 4.88 mm (0.1875 in.)
PHA118: 6.4 mm (0.25 in.)
PHA124: 6.4 mm (0.25 in.)
Auger Points
Auger dimensions
Cutting Edges
Set-up time
Warranty
Additional information
