Details New

Frontier™ Expandable Front Snow Blade

AF13E

Key Features & Specs
  • Hydraulic width adjustment up to 10 ft. (3 m.)
  • Mounts directly to tractor frame
  • Clears snow near structures with reversed blade
  • Hydraulic hoses made for extremely low temperatures

FEATURES
SPECIFICATIONS
EXPAND / CLOSE All
Improve Productivity with the Expandable Snow Blade
#

Reduce the number of passes and pull snow from enclosed spaces, the AF13E Series Front Snow Blade makes quick work of snow-removal jobs. Using hydraulics to expand the blade horizontally, the AF13E blade has 6-to-10’ of working width, creating professional-grade results in less time.

Front-Mount Improves Capacity and Visibility
#
#

The AF13E Series Front Snow Blade comes equipped with a front blade lift system allowing the snow blade to articulate up to 10°. Providing increased capacity and functionality, over loader-mounted blades, the lift mounts directly onto the loader-mount locations and tractor frame. The hydraulics utilize the dual mid-SVC to expand and contract the blade, eliminating the need for third function and saving costs. Sitting close to the tractor frame operators will also have improved visibility to the snow blade and snow.

Hydraulics Designed for Cold Temperatures
#
#

Designed for ultra-low temperatures, the AF13E hydraulic hoses use ultra-low temperature resistant synthetic rubber.

Inverted Blade Removes Snow Up Close
#

Pull snow out of enclosed areas and away from objects with the inverted blade on the AF13E Expandable Front Snow Blade. The inverted blade has the capability to reach snow that other blades cannot such as, up close to buildings, garage doors, walls, and other enclosed structures.

TIVAR Cutting Edge
#

Helping to reduce harsh contact and surface markings, the tivar cutting edge that comes standard on the AF13E, is the ultimate choice for a range of surface types, including fragile ones such as paved stone.

Easy Serviceability
#
#

Communized cylinder components make serviceability easier than ever.

EXPAND / CLOSE All
Key Specs
Cutting width
Current series style
Moldboard
Angle/pivot
General
TypeInverted
Tractor HP Requirements (min.-max.)45-75 hp
Working Depth ControlHydraulic
Dimensions
Width
Height
Depth
Cutting width
Width, Working MIN6ft 5in. (1955 mm)
Width, Working MAX10ft. 5in. (3175 mm)
Width, Overall MAX10ft. 8.13in (3254 mm)
Height, Overall56in. (1422mm)
Weight, Shipping2000 lbs.
Weight, Operating1680 lbs.
Height, Blade29in. (736.6mm)
Weight, Blade1147 lbs.
Depth, Blade27in. (685.8mm)
Weight, Hitch415 lbs.
Distance, To Ground lifted21in. (533.4mm)
Distance, Under the ground6in. (152.4mm)
Distance, Bumper to Cutting Edge24.5in (622.3mm)
Cutting Edge
Height, Cutting Edge5in. (127mm)
Thickness, Cutting Edge1in. (25.4mm)
TypeUHMW
Skid Shoe
Height, Skid Shoe Cutting Edge5in. (127mm)
Thickness, Skid Shoe Cutting Edge1in. (25.4mm)
Type, Skid ShoeUHMW
Skid Shoe Adjustment-2 @ 8
Frame
Thickness, Frame (in.)1/4
Harness Tube (in.)3 x 3
Extension Hydraulic Cylinder
Double Hydraulic Cylinders3 x 24
Flow Divider BlockYes
Lift Hydraulic Cylinder
Double Hydraulic Cylinder2 x 10
Ground Clearance (in.)20
Attachment carrier
Weight
Operational
Shipping
Moldboard
Thickness
Height
Angle/pivot
Standard adjustment
Degrees (each side)
Hydraulic cylinders
Skid shoes
Set-up time
Warranty
Additional information
