Trenchers

DT11 Series

Key Features & Specs
  • 14-in. discharge auger
  • Durable chain for light-duty jobs
  • iMatchTMcompatible

FEATURES
SPECIFICATIONS
EXPAND / CLOSE All
Chain is durable for light-duty trenching jobs
Cuts 15.2-cm (6-in.) wide and digs up to 91.4-cm (36-in.) deep Cuts 15.2-cm (6-in.) wide and digs up to 91.4-cm (36-in.) deep

The trencher's durable chain gets under the frost line, cutting a 15.2-cm (6-in.) width and digging a channel up to 91.4-cm (36-in.) deep.

35.6-cm (14-in.) discharge auger lightens workload
Pushes dirt aside, allowing smooth operation Pushes dirt aside, allowing smooth operation

The 35.6-cm (14-in.) discharge auger makes light work when moving dirt. It easily pushes dirt aside, allowing the trencher to run smoothly without clogging.



The discharge auger also helps to prevent unnecessary backfill into newly trenched channels.

EXPAND / CLOSE All
Dimensions
Trench depth with auger at 65-degree angle91.4 cm
36 in.
Overall length200.7 cm
79 in.
Overall width96.5 cm
38 in.
Overall height73.7 cm
29 in.
Weight
Operating287.1 kg
633 lb
Shipping294.8 kg
650 lb
Tractor compatibility
Hitch
CompatibilityCat. 1
iMatchTM compatible (Cat. 1)
Chain
Chain typeRated anti back flex: 17,236.5 kg
38,000 lb
Chain width15.2 cm
6 in.
Chain pitch4.2 cm
1.654 in.
Length in pitches64
PTO
Speed540 rpm
Overload protectionSlip clutch
Spoil auger
Diameter35.6 cm
14 in.
Discharge reach53.3 cm
21 in.
Hydraulic system
Parking stands
Duty
Shipping
Set-up time
Warranty
Additional information
