Steel Cutting Edge (Base)

Urethane Cutting Edge (Field Installed)

The reversible cutting edge enhances performance and extends working life, for improved performance on textured surfaces the Urethane Cutting Edge is available.

Steel Skid Shoe (Base)

Urethane Skid Shoe (Field Installed)

The steel skid shoe extends the life of the cutting edge while avoiding damage to the working surface. To prevent damage to textured surfaces, while prolonging the life of the cutting edge, Urethane Skid Shoes are available.

The trip edge protects the blade, loader, and tractor if the edge of the blade contacts an obstacle.

With the pin and hole blade angle adjustments an operator can manually adjust the angle of the blade, choosing from five adjustments for an overall 30-degree rotation

Toolless attachment of the front blade with the Quick-Change attachment carrier increases uptime.

To connect, align the attachment carrier with the hooks of the front blade, raise the boom for the carrier to engage the hooks of the blade, and roll back the attachment carrier. Then install the retaining pins, and the carrier is ready to work.

The hydraulic angle kit allows angling of the front blade up to 30 degrees in any position to the left or right of the center.

*Requires third-function hydraulics (see loader options for third-function kit information).

*Compatible with AF10F serial number lXFAF10FPJ002201 and higher.

The reversible urethane cutting edge improves performance by preventing damage to textured surfaces during snow removal.

The urethane skid shoe kit enhance performance by preventing damage to textured surfaces, while prolonging the life of the cutting edge.
