Details New

Snow Pushes

AS10F Series

Key Features & Specs
  • Reversible cutting edge
  • Heavy duty welded steel end plates
  • Quick-attach capability

FEATURES
SPECIFICATIONS
EXPAND / CLOSE All
Increased uptime with Quik-Tatch capability
Quik-Tatch capable Quik-Tatch capable

Hook up the snow push by lining up the loader’s connecting point to the attachment frame, picking up the attachment, and locking it in place.

Multiple working widths to match tractor

Choose between two working widths to match the operator’s current tractor requirements: 121.9 cm or 152.4 cm (48-in. or 60-in.).

Reversible cutting edge increases life of snow push
Rubber cutting edge Rubber cutting edge

The cutting edge is reversible and adjustable to increase the wear life of the part. The steel blade comes standard, but an optional rubber blade is available.

Options available to increase ease of use
Pull-back kit
Optional pull-back kit Optional pull-back kit

An optional pull-back kit is available to reach snow other blades cannot reach, such as away from a garage, retaining wall, and curbs. It is available in either a steel edge or a rubber edge.

Poly skid shoes
Optional poly skid shoes Optional poly skid shoes

Optional skid shoes are available to extend the life of the snow push and provide additional non-marking protection.

Edge marker kit
Optional edge marker Optional edge marker

An optional edge marker kit is available to assist operators in maneuvering close to objects that can be damaged or may damage the push.

EXPAND / CLOSE All
Dimensions
Width128.5 cm
50.6 in.
Height49.0 cm
19.3 in.
Depth54.9 cm
21.6 in.
Cutting width121.9 cm
48.0 in.
Attachment carrier
Weights
Equipment64.4 kg
142 lb
Shipping
Cutting edge
Rubber
Steel, spring resetYes
Moldboard
Thickness12 gauge
2.66 mm
0.1046 in.
Height48.3 cm
19.0 in.
Capacity
Skid shoes
Set-up time
Warranty
Additional information
