Details New

Bale Spear

AB14G

Key Features & Specs
  • Quick, easy connection
  • Rugged, tubular frame
  • Replaceable spears for extended implement life

FEATURES
SPECIFICATIONS
EXPAND / CLOSE All
Quick, easy connection
AB14D fits 600 and 700 Series Loaders AB14D fits 600 and 700 Series Loaders
AB14G is global and fits all series loaders AB14G is global and fits all series loaders
AB14A fits 800 Series Loaders AB14A fits 800 Series Loaders

The AB14 Series Bale Spears are equipped with quick-change, quick-attach, and global attaching systems. These systems create ease and accuracy for the operator. The proper attachments are as follows:

  • AB14D – 600 and 700 Series Loaders
  • AB14A – 800 Series Loaders
  • AB14G – Global Loaders
Rugged, tubular frame built to withstand harsh conditions
Rugged, tubular frame Rugged, tubular frame
#

The frame on the Frontier™ AB14 Series is a square, tubular design, making it extremely strong and durable.

Replaceable tines for extended implement life
Hardened steel tines enhance implement durability Hardened steel tines enhance implement durability
#

The tines on the Frontier™ AB14 Series are made out of hardened steel and are replaceable.

EXPAND / CLOSE All
Key Specs
Current series styleGlobal
SquareQuantity
One
Size
Large square
Weight
907.2 kg
2,000 lb
Dimensions
Overall height43.2 cm
17 in.
Overall width63.5 cm
25 in.
Overall length177.8 cm
70 in.
Attachment carrier
Weight
Operational176.9 kg
390 lb
Shipping210.9 kg
465 lb
Spears
PrimaryLocation
Top
Quantity
Two
Size
5.1x124.5 cm
2x49 in.
StabilizingLocation
Bottom
Quantity
2
Size
3.2x63.5 cm
1.25x25 in.
Bale
RoundQuantity
Two
Size
Less than: 1.823 m
6 ft
Maximum weight
907.2 kg
2,000 lb
SquareQuantity
One
Size
Large square
Weight
907.2 kg
2,000 lb
Set-up time
Warranty
Additional information
