- Straight blade aerator rotor aerates soil and incorporates seed in one step
- Rear cultipacker levels and smooths seedbed
- Front gauge roller levels ground, controls seed depth
- iMatchTM compatible
Specs & Compare
| Specs & Compare | ||||
|---|---|---|---|---|
| John Deere TR20 Series Overseeders |
Dimensions
| Working width | 147 cm 58 in. |
|||
|---|---|---|---|---|
| Overall width | 168 cm 66 in. |
|||
| Height |
Weight
| Shipping weight | 539 kg 1188 lb |
|||
|---|---|---|---|---|
| Operational weight | 453 kg 998 lb |
Tractor compatibility
| PTO hp | 19-37 kW 25-50 hp |
|||
|---|---|---|---|---|
| PTO rpm | 540 rpm | |||
| Rotor rpm | 231 rpm |
Capacity
| Hopper | 150 m3 4.26 bu |
|---|
High carbon tapered steel pins
| Quantity | ||||
|---|---|---|---|---|
| Length |
Flanges
| Quantity | 18 |
|---|
Blades
| Quantity | 52 |
|---|
Hitch
| 3-point type | ||||
|---|---|---|---|---|
| iMatch™ compatible | Yes |
Set-up time
| Labor hours | 0.5 hours |
|---|
Warranty
| Time period | One year |
|---|
Additional information
| Date collected |
|---|
