- Reduce transport time between fields with an 8-row folding corn head
- Size residue less than 6 inches with RowMax™ Chopping Stalk Rolls
- Reduce overlap and operate hands-free with optional AutoTrac™ RowSense™
Specifications
Add Model
| Specifications | ||||
|---|---|---|---|---|
| Select up to 4 models to compare specifications | John Deere CF8 Folding Corn Head |
Key Specs
| Approximate overall width | With 70-cm (27.6-in.) row spacing: 6.17 m 20.25 ft With 75-cm (29.5-in.) row spacing: 6.1 m 20.01 ft With 76.2-cm (30-in.) row spacing: 6.15 m 20.4 ft With 91.4-cm (36-in.) row spacing: 7.7 m 25.2 ft With 96.5-cm (38-in.) row spacing: 7.6 m 25 ft |
|||
|---|---|---|---|---|
| Approximate folded width | ||||
| Row spacings | 70, 75, 76.2, 91.4, or 96.5 cm 27.6, 29.5, 30, 36, or 38 in. |
|||
| Deck plate adjustment | Hydraulic adjustment | |||
| Gathering chain adjustment | Spring loaded, self-adjusting | |||
| Gathering chains | Heavy-duty, 620, endless steel roller chain with chromed pins (no master connecting link) |
Corn Head
| Gathering points | Four-position, low-profile floating type hinged above gathering chains | |||
|---|---|---|---|---|
| Center and outer gatherings | Hinged, quickly removable | |||
| Gathering chains | Heavy-duty, 620, endless steel roller chain with chromed pins (no master connecting link) | |||
| Minimum clearance between gathering chains and ground | 32 mm 1.25 in. |
|||
| Row unit drive | Enclosed, submerged-in-lubricant gearbox, driven by single input hexagon shaft | |||
| Gathering chain adjustment | Spring loaded, self-adjusting | |||
| Stalk rolls | Opposed, intermeshing, and chopping (two per row-unit) | |||
| Deck plate adjustment | Hydraulic adjustment | |||
| Slip clutch | One per row-unit plus auger drive | |||
| Trash knives | Full-length, one-piece, heat-treated steel | |||
| Stalk deflectors | Factory-installed option |
Dimensions
| Approximate overall width | With 70-cm (27.6-in.) row spacing: 6.17 m 20.25 ft With 75-cm (29.5-in.) row spacing: 6.1 m 20.01 ft With 76.2-cm (30-in.) row spacing: 6.15 m 20.4 ft With 91.4-cm (36-in.) row spacing: 7.7 m 25.2 ft With 96.5-cm (38-in.) row spacing: 7.6 m 25 ft |
|||
|---|---|---|---|---|
| Approximate folded width | Points in operating position (lowered) 3.2 m 10.58 ft Points folded up (service position) With 70-cm (27.6-in.) row spacing: 2.6 m 8.58 ft With 75-cm (29.5-in.) row spacing: 2.6 m With 76.2-cm (30-in.) row spacing: 2.6 m With 91.4-cm (36-in.) row spacing: 3.2 m 10.58 ft With 96.5-cm (38-in.) row spacing: 3.2 m |
|||
| Approximate shipping weight (includes shipping skid) | With 70-cm (27.6-in.) row spacing: 2667 kg 5880 lb With 75-cm (29.5-in.) row spacing: 4275 kg 9425 lb With 76.2-cm (30-in.) row spacing: 2917 kg 6431 lb With 91.4-cm (36-in.) row spacing: 2764 kg 6094 lb With 96.5-cm (38-in.) row spacing: 3965 kg 8741 lb |
|||
| Row spacings | 70, 75, 76.2, 91.4, or 96.5 cm 27.6, 29.5, 30, 36, or 38 in. |
|||
| Standard weight | With 70-cm (27.6-in.) row spacing: non StalkMaster™ 2670 or StalkMaster 2917 kg 5886 or 6431 lb With 75-cm (29.5-in.) row spacing: non StalkMaster 2658 or StalkMaster 2764 kg 5860 or 6094 lb With 76.2-cm (30-in.) row spacing: non StalkMaster 2575 or StalkMaster 2829 kg 5677 or 6237 lb With 91.4-cm (36-in.) row spacing: non StalkMaster 2760 or StalkMaster 3074 kg 6085 or 6777 lb With 96.5-cm (38-in.) row spacing: non StalkMaster 2487 or StalkMaster 2667 kg 5483 or 5880 lb |
Additional information
| Date collected | 15 June 2020 |
|---|
