- Adjustable hay compressor
- Hydraulic bale tension available
- Large windrow capacity
- Automatic lockout
Specs & Compare
Add Model
| Specs & Compare | ||||
|---|---|---|---|---|
| Select up to 4 models to compare specifications | John Deere 348 Small Square Baler |
Key Specs
| Minimum PTO | 26 kW 35 PTO hp |
|||
|---|---|---|---|---|
| Pickup width | 187.9 cm 74 in. |
|||
| Bale size | Height x width 36×46 cm 14×18 in. Length 30.5 to 127 cm 12 to 50 in. |
|||
| Bale Density adjustment | Optional | |||
| Plunger – Strokes/minute | 93 spm |
Bale size
| Height x width | 36 x 46 cm 14 x 18 in. |
|||
|---|---|---|---|---|
| Length | 30.5 to 127 cm 12 to 50 in. |
|||
| Maximum volume | ||||
| Dry bale weight |
Pickup
| Pickup width | 187.9 cm 74 in. |
|||
|---|---|---|---|---|
| Tooth bars/teeth | 6 bars, 156 teeth | |||
| Lift control | Crank (hydraulic optional) | |||
| Pickup diameter | 49.5 cm 19.5 in. |
|||
| Compression rack rods |
Auger and feeder forks
| Diameter | 41 cm 16 in. |
|||
|---|---|---|---|---|
| Length | 154.9 cm 61 in. |
|||
| Feed opening |
Plunger
| Strokes/minute | 93 spm | |||
|---|---|---|---|---|
| Stroke length |
Typing mechanism
| No. of knotters | 2 | |||
|---|---|---|---|---|
| Twine capacity | 8 | |||
| Twine type | Plastic or sisal | |||
| Knot strength (minimum required) | ||||
| Central lube system | Optional | |||
| Wire twisters | ||||
| Wire ball capacity | 4 | |||
| Extra Twine storage / number of ball | ||||
| Twine size runnage |
Baler dimensions
| Length w/ short tongue | ||||
|---|---|---|---|---|
| Length w/ long tongue | 576.5 cm 227 in. |
|||
| Width | 274.3 cm 108 in. |
|||
| Height with fork cover | 170.2 cm 67 in. |
|||
| Weight empty | 1411 kg 3110 lb |
Tractor requirements
| PTO speed | 540 rpm | |||
|---|---|---|---|---|
| Minimum PTO | 26 kW 35 PTO hp |
Drive mechanism
| Driveline | Equal angle 3 joint category 4 | |||
|---|---|---|---|---|
| Optional driveline | Equal angle 3 joint category 5 | |||
| Pickup | Belt | |||
| Plunger | Gear and shaft | |||
| Knotters | Gear and shaft | |||
| Feeder forks | Gear and shaft | |||
| Diameter of flywheel | ||||
| Weight of flywheel |
Drivetrain protection
| PTO | ||||
|---|---|---|---|---|
| Gearbox | ||||
| Pickup | Belt slip | |||
| Needles | Shear bolt/plunger head stop | |||
| Knotters | Shear bolt |
Tires
| RH Standard tire size | 26×12.0-12, 4 ply | |||
|---|---|---|---|---|
| RH Optional tire size | ||||
| LH Standard tire size | 11L-14, 6 ply | |||
| LH Optional tire size | ||||
| Gauge Wheels | 1 optional | |||
| Pickup Gauge Wheels Tires Size | 16.5×6.50-8 |
Lights
| Work | Optional | |||
|---|---|---|---|---|
| Transport lights |
Density Control System
| Adjustable Bale Density | Mechanical crank | |||
|---|---|---|---|---|
| Bale Density adjustment | Optional | |||
| Bale Counter | ||||
| Cab remote control adjustment Bale Density | ||||
| Design | ||||
| Manual adjustment Bale Density |
Bale Ejector
| Available | Optional |
|---|
Bale Chute
| Regular bale chute | ||||
|---|---|---|---|---|
| Short chute | Optional | |||
| Long chute | Optional | |||
| Side bale drop chute | Optional | |||
| Wagon hitch | Optional | |||
| Less bale chute |
Additional information
| Date collected |
|---|
Double forks
| Feed opening | ||||
|---|---|---|---|---|
| Protection | ||||
| Type |
